Identifying
Sheppard
D
type
gears

Identify
the
gear
size

Begin
by
identifying
the
gear
size.

This
number
is
cast
or

embossed
in
the
main
gear
housing.

EX:

HD94
Auto

Identify
the
gear
part
number

The
gear
power,
model
and
series
identifiers
are
located
on
a
machined
surface

around
the
output
shaft
of
the
gear.

If
the
gear
is
still
on
the
vehicle,
these
numbers

may
be
hidden
behind
the
pitman
arm.

Turning
the
wheels
all
the
way
to
the
left
will

help
get
the
pitman
arm
out
of
the
way
to
identify
these
characters

EX:

HD94

P

D

3

Gear
Size
Power
Model
Series

HD94
P/S
Alpha
Alpha/Num

SD-­‐110
P
Alpha
Alpha/Num

XD-­‐120
P
Alpha
Alpha/Num

If
all
characters
are
legible
refer
back
to
the
ProSteering
application
guide
to

determine
the
exact
PSG
steering
gear
number.

If
the
pin
stamped
characters
around

the
output
shaft
are
not
legible
we
will
use
the
number
of
frame
mounting
pads,
input

shaft
type,
relief
valve
option,
and
number
of
lines
to
identify
the
gear
and
determine

the
correct
PSG
part
number.
